fine pitch product specifications - Data Sheet

Orex MetaTech Series

Smart COB, Smart Budget

Pixel pitch: 0.9mm / 1.25mm /

Cabinet size: 600*337.5*39.75mm / 600*337.5*51.3mm

Operating environment: Indoor

Get a Inquiry Back

Cost-effective Shared Pixel Technology


Parameter

Download
Pixel Pitch (mm) 0.9 1.25
Encapsulation COB(Common cathode) COB(Common cathode)
Module Size (mm) 150*168.75 150*168.75
Cabinet Size (mm) 600*337.5*39.75 600*337.5*39.75
Cabinet Resolution (W×H) 320*360/320*720 240*270/240*540
IP Grade Front IP54 Front IP54
Weight (kg/cabinet) 4/7.9 4/7.9
White Balance Brightness (nit) 600 600
Horizontal / Vertical Viewing Angle 160 160
Power Consumption(W/㎡) 320/640 320/640
Refresh Rate(Hz) 1920-3840 1920-3840
Control System Nova Nova
Certification EMC CLASS-A EMC CLASS-A
